Air Compressor Filter

Hankison Coalescing Filter Replacement - E5-20

Product description: Hankison Coalescing Filter Replacement - E5-20
INQUIRY EMAIL

Structure: Inside and outside is the metal nets,the middle is high density glass fiber and gas separation material, flange connection with sealing ring

1.Fillter efficiency:99.99%
2.Media rating: 0.1μm
3.Working Life:4200h-5600h
4.Material:USA HV Company fiber glass Microns fiber glass
5.Glass fiber shape:folding or plane
6.outside:imported sponge with very high quality
7.Pressure difference control : 0.08-0.1Mpa

Model Class FLOW Rate NM3/min	E1 Degreasing deodorant filter element	E3 Super UF Degreasing Filter Element	E5 UF Degreasing Filter Element	E7 Ventilation Pipe Filter Element	E9 Separate Filter Element	Filter Precision (μm)	Residual Oil Component (ppm)
0.57	E1-12	E3-12	E5-12	E7-12	E9-12	E1:0.01	0.001
1	E1-16	E3-16	E5-16	E7-16	E9-16	E3:0.01	0.001
1.72	E1-20	E3-20	E5-20	E7-20	E9-20	E5:0.01	0.01
2.9	E1-24	E3-24	E5-24	E7-24	E9-24	E7:1	1
4.9	E1-28	E3-28	E5-28	E7-28	E9-28	E9:3	5
7.2	E1-32	E3-32	E5-32	E7-32	E9-32
11	E1-36	E3-36	E5-36	E7-36	E9-36
14	E1-40	E3-40	E5-40	E7-40	E9-40
18	E1-44	E3-44	E5-44	E7-44	E9-44
